Advantage

1.Industrial computer control,easy operation,

2.Low noise,more environmental.

2.High performance and stable quality

3.Fast delivery

4.Full after-sale service

Functions:

1.The detection range: BOSCH, DENSO, DELPHI, SIMENS etc brands Injectors

2.Full- automatic control the common rail injectors’ testing

3.Test the tightness of the high-pressure common rail injector and observe its atmospheric effects

4.Measuring the oil injection quantity and oil return quantity of common rail injector under each working state

5.It can set common rail injector’s injection status, and measuring the oil quantity.

6.It can proceed high pressure washing towards the common rail injector

7.Users can custom setting the characteristics of rail pressure, pulse width and oil measuring time

8.The injector testing data report can print out after the testing

Bosch EPS200 common rail injector test bench

Technical Parameters:

1. The rated output power: 5.5KW

2. The main power supply: 380V/50HZ 3-phase

3. The speed of the test bench: 0 ~ 3600 r / min

4. The continuous injection time: 0 ~ 1000 time

5. Rail pressure: 0 ~ 1800 bar

6. Pulse width: 100 ~ 3000μs

7. Fuel oil temperature: 40 ± 2 ℃

8. The test oil filtration rating: less than 5μ

9. Oil tank capacity: 15L

10. The overall size (MM): 880 × 775 × 1400

11. Weight: 300 kg

Skype:alice.chen519

Whatsapp:008618205489639

Taian North Test Equipment Factory is appointed by the country as the professional manufacturer for producing the oil injection pump test bench. It gets the technique support from Tianjin university,Tianjin University of technology,Shandong University of science and technology.
The factory integrates scientific research, exploitation with selling. "North" oil injection pump test bench ,which is the main product, takes in the advanced technology in China,meanwhile, they have innovated in the system of digital, computer control, and this makes the dependability and stability of the equipments stand in the first place in China.
